Alimentare electrica (Ph-V-Hz)
220-240V,1Ph,50Hz
Amperaj incalzire (A)
11(1.3~12.2)
Amperaj racire (A)
11.5(1.8~13.8)
Compresor Amperaj in functionare (A)
9.3
Compresor Capacitate (Btu/h)
7600
Compresor Model
KTM240D43UKT
Compresor Putere consumata (W)
2045
Compresor Refrigerant oil/oil charge (ml)
ESTER OIL VG74 620
Consum electric incalzire (W)
2400(300~2750)
Consum electric racire (W)
2600(420~3150)
Control temperatura
Telecomanda
Debit aer UI (Hi/Mi/Lo) (m3/h)
980/817/662
Exterior (racire/incalzire) (℃)
-15～50/-25～30
Incalzire sezoniera Clasa eficienta energetica
A+++
Incalzire sezoniera Pdesignh (kW)
4.8
Incalzire sezoniera SCOP (W/W)
5.1
Incalzire sezoniera Temperatura de balans (℃)
-7
Motor ventilator UE Model
ZKFN-80-8-3
Motor ventilator UE Putere (W)
115
Motor ventilator UE Turatie (r/min)
830/700/550
Motor ventilator UI Condensator electric (uF)
―
Motor ventilator UI Model
ZKFP-58-8-1-5
Motor ventilator UI Putere (W)
58.0
Motor ventilator UI Turatie(Hi/Mi/Lo) (r/min)
1150 / 1000 / 850
Nivel presiune sonora UE (dB(A))
59
Presiune de proiect (MPa)
4.3/1.7
Presiune sonora UI (Hi/Mi/Lo/Si) (dB(A))
45/40.5/36/29.5
Putere Incalzire Capacitate (Btu/h)
25000(5500~27000)
Putere max. consumata (W)
3500
Putere Racire Capacitate (Btu/h)
24000
(7100~27000)
Putere sonora UE (dB(A))
67
Putere sonora UI (Hi) (dB(A))
59
Racire sezoniera Clasa eficienta energetica
A++
Racire sezoniera Pdesignc (kW)
7.0
Racire sezoniera SEER (W/W)
6.1
Refrigerent Masa incarcatura (Kg)
1.42
Schimbator UI a.Numar spirale
2.0
Schimbator UI a.Numar spirale_1
1.6
Schimbator UI b.Pas tub(a)x pas linie(b) (mm)
21x13.37
Schimbator UI b.Pas tub(a)x pas linie(b) (mm)_1
21x22
Schimbator UI c.Spatiere (mm)
1.3
Schimbator UI c.Spatiere (mm)_1
1.3
Schimbator UI e.Diametru tub (mm)
Φ7, tub canelat
Schimbator UI e.Diametru tub (mm)_1
Φ7,Inner groove tube
Schimbator UI f.Lungime spira x inaltime x latime (mm)
780x210x26.74+780x105x26.74
Schimbator UI f.Lungime spira x inaltime x latime (mm)_1
900*44*609
Schimbator UI g. Numar de circuite
4
Schimbator UI g. Numar de circuite_1
5
Suprafata aplicatie minim maxim (m2)
32-47
Temperatura limita pentru incalzire (℃)
-15
Temperaturi de lucru Intern (racire/incalzire) (℃)
17～32/0～30
Tevi refrigerent Diametru tevi refrigerent lichid/gaz (mm/inch)
Φ9.52(3/8’‘)/Φ15.9(5/8’‘)
Tevi refrigerent Diferenta max. de nivel (m)
25
Tevi refrigerent Lungime maxima traseu teava (m)
50
UE Ambalaj (W*D*H) (mm)
995x398x740
UE Dimensiuni (W*D*H) (mm)
890x342x673
UE Masa Net/Gross (Kg)
42.9/45.9
UI Ambalaj (W*D*H) (mm)
1120x405x310
UI Dimensiuni(W*D*H) (mm)
1040x220x327
UI Masa Net/Gross (Kg)
12.3/15.8
